Breathing Lines for Anaesthetic Machines and Ventilators Water Catchment Cup Tube--ANTS Medical Ltd}

Product parameters

Product No. :0614012~0616721

Scope of application:

For clinical use with anaesthetic machines or ventilators to establish a respiratory connection for patients.

Standard configuration:

The product consists of a water collection cup tube and optional accessories. Optional: airbag, anaesthetic mask, extension tube, artificial nose.

The last:Breathing Lines for Anaesthetic Machines and Ventilators Coaxial Tubes Next up:Breathing Lines for Anaesthetic Machines and Ventilators Single Pipe Circuit

Product details

Product features:

1. Standard fittings (15mm, 22mm);

2、The body of the tube is a corrugated tube made of EVA+PP material;

3. Specifications: children (M), adults (L);

4. Available models: 1.2m, 1.5m, 1.6m, 1.8m, 2.0m, 2.3m, 2.5m;

5. Optional accessories: airbag, anaesthetic mask, extension tube, artificial nose;

6. The product is a sterile medical device and cannot be reused.

Specification configuration:

Basic configuration of breathing lines for anaesthetic machines and ventilators

Serial number	Product number	Product specifications	Pipe length	Optional
1	0614012~0614961	KL-8006-Ⅳ-L	1.2m	3L airbag, anaesthetic mask, extension tube, artificial nose
2	0614971~0615121	KL-8006-Ⅳ-L	1.5m	3L airbag, anaesthetic mask, extension tube, artificial nose
3	0615131~0615281	KL-8006-Ⅳ-L	1.6m	3L airbag, anaesthetic mask, extension tube, artificial nose
4	0615291~0615441	KL-8006-Ⅳ-L	1.8m	3L airbag, anaesthetic mask, extension tube, artificial nose
5	0615451~0615601	KL-8006-Ⅳ-L	2.0m	3L airbag, anaesthetic mask, extension tube, artificial nose
6	0615611~0615761	KL-8006-Ⅳ-L	2.3m	3L airbag, anaesthetic mask, extension tube, artificial nose
7	0615771~0615921	KL-8006-Ⅳ-L	2.5m	3L airbag, anaesthetic mask, extension tube, artificial nose
8	0615931~0616081	KL-8006-Ⅳ-M	1.2m	1L airbag, anaesthetic mask, extension tube, artificial nose
9	0616091~0616241	KL-8006-Ⅳ-M	1.5m	1L airbag, anaesthetic mask, extension tube, artificial nose
10	0616251~0616401	KL-8006-Ⅳ-M	1.6m	1L airbag, anaesthetic mask, extension tube, artificial nose
11	0616411~0616561	KL-8006-Ⅳ-M	1.8m	1L airbag, anaesthetic mask, extension tube, artificial nose
12	0616571~0616721	KL-8006-Ⅳ-M	2.0m	1L airbag, anaesthetic mask, extension tube, artificial nose
